Ratings from ANSI 150 up to ANSI 2500 (B10 to B100 for EN ratings);
Wide operating temperature range (-55 °C to 566 °C, -196°C with optional extended bonnet);
Quick change design up to maximum allowed working temperature;
High flow capacity thanks to optimized body shape design;
High rangeability thanks to Cascade Clearance Flow (CCF) plug design;
Sealing class V IEC 60534-4 up to 566 °C for balanced plug with pilot (“flow to close” for compressible fluid applications) or metal C-ring seal for all applications;
Unbalanced Contoured plug version available up to DN 8” for dirty fluids service;
Soft seat ring insert, to comply with IEC 60534-4 leakage class VI;
Partially extended, finned bonnet shape, to comply with all working temperatures.
